Avaya IP500 V2A Control Unit 700514867

FEATURES

• 4 Base Card Slots – Supports the following base cards: Digital Station 8A, Analog Phone 2, Analog Phone 8, Combination ATM, Combination ATM V2, ETR 6, TCM 8, VCM 32, VCM 32 V2, VCM 64, VCM 64 V2, Unified Communications Module V2, 4-Port Expansion
• Trunk Cards – Supports the following trunk interface cards when installed on IP500 Base Cards: IP500 ATM 4, IP500 ATM 4 V2, IP 500 PRI 1, IP 500 PRI 2
• 8 Integrated Expansion Ports – Supports the following external expansion modules: Digital Station 16/30; Phone 8/16/30; Analog Trunk 16
• 2 SD Card Slots – Supports system SD card (required) and optional SD card
• Voicemail Channels – Maximum 40 usable for Voicemail Pro/TAPI WAV connection sessions
• 2 LAN Ports – Full duplex 10/100 Mbps; managed layer 3 Ethernet switch
• Additional Ports – Music on-hold, DTE port, external relay switch for door entry controls, integral WAN port

COMPATIBILITY AND REQUIREMENTS

• Requires Avaya IP500 V2 System SD Card (sold separately, see options above)
• Supports Avaya IP Office Release 11.1 or higher
• Avaya IP Office Basic Edition
• Avaya IP Office Essential Edition (Requires Optional Software Upgrade)
• Avaya IP Office Preferred Edition (Requires Optional Software Upgrade)
• Avaya IP Office Subscription Edition (Requires Optional Software  Upgrade)

PACKAGE CONTENTS

• Avaya IP500 V2A Control Unit
• US Power Cord
